ILSCO 25006 UL/CSA Listed 1/4 Inch Diameter Thin Wall Heat Shrink

Manufacturer: Ilsco | Catalog # 25006 | QED Part # 4952048
$67.12 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 8 days
Primary Spec Sheet Product Catalog Page
ILSCO Heat Shrinkable Tubing, Thin Wall, Polyolefin material, UL 224 Recognized, C22.2 No. 198.1, Copper/Aluminum Primary Conductor 14 Str - 16 Str and 14 Sol - 16 Sol, rated for 600 V, Disk dispenser, primary color Black, 96 in cut length, 0.125 IN recovered OD,

Technical Information

Applications
For Shrink Wrap
Conductor Size
16-14 AWG
Dielectric Strength
600 V/Mil
Shrink Ratio
2:1
Standard
CSA,E2186,UL
Temperature Rating
-55 to 135 degrees C
Type
HSTW:THIN HEAT SHRINK
Voltage
600 Volt
Wire Size
16-14 AWG

Manufacturer Information

Brand
Ilsco
Sub Brand
ClearChoice

General Product Info

12-Digit UPC
783669421385
Color
Black
Product UPC
78366942138

Dimensions

Height
1.063 Inch
Length
2.43 m
Width
.656 in
Overview
  • Designed to require fewer turns to reach required torque and meet or exceed UL pull out and dielectric test requirements
  • Square-wire zinc-plated spring instantly adjusts to the shape and size of the splice
  • Flame-retardant properties resist heat distortion up to 105 degrees Celsius/221 degrees Fahrenheit
  • High-dielectric shell features deep skirt design to prevent exposure of bare wire
  • Rated at 600V max in building wire and at 1000V max in lighting, fixtures/luminaries and signs
  • Copper to copper connections only
