Ilsco GTA-250-250-W/C Aluminum Parallel Tap Connector, Dual Rated, Main Conductor Range 250-1/0, Tap Range 250-6, Tin Plated, UL, CSA, Includes Cover

Manufacturer: Ilsco | Catalog # GTA-250-250-W/C | QED Part # 49177
$121.32 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 8 days
Primary Spec Sheet
ILSCO Parallel Tap Connector, Mechanical connection, Dual Rated, Aluminum material, Tin plated connector, UL 486A/B Listed, C22.2 No. 65-03, Copper/Aluminum Primary Conductor 250 kcmil - 1/0 Str, Copper/Aluminum Secondary Conductor 250 kcmil - 6 Str, 2 conductors, Supplied with insulating cover insulation, Drive Type Main 5/16 Internal Hex, Drive Type Tap 5/16 Internal Hex, rated for 600 V, primary color Silver, 1 poles,

Technical Information

Applications
Parallel Tap Connector
Material
Aluminum
Number of Conductors
2
Number of Ports
1
Tc Connection
Mechanical
Temperature Rating
90 degrees C
Type
GTA:PARALLEL TAPS AL/CU
Voltage
600 Volt

Manufacturer Information

Brand
Ilsco
Sub Brand
ILSCO

General Product Info

12-Digit UPC
783669347685
Color
Silver
Finish
Tin Plated
Product UPC
78366934768
