LIT NBRG-8-KIT Bridge

Manufacturer: Lithonia Lighting | Catalog # NBRG 8 KIT | QED Part # 4208482
$626.04 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 10 days
Primary Spec Sheet
The nLight Bridge increases the number of lighting control zones in an nLight system with each Bridge having 8 RJ-45 ports that are daisy-chained to other nLight devices to create zones forming an integral component of the communication backbone in an nLight network

Technical Information

Applications
Education,Government,Healthcare,Hospitality,House Of Worship,Manufacturing,Offices & Banks,Retail,Sports And Recreation,Warehouses
Material
Plastic
Mounting Type
Surface,Unit To J Box
Standard
C-UL-US,UL
Type
System Controller
Voltage
120 Volt
Wattage
Not Applicable Watt

Manufacturer Information

Brand
nLight, Inc.

General Product Info

12-Digit UPC
784231075357
Color
White
Environment
Indoor
Environmental Conditions
Indoor
Finish
Gloss
Product Type
System Controller
Product UPC
78423107535
Weight
1.133 lb

Dimensions

Height
5-1/2 Inch
Length
7-1/2 Inch
Warranty Length
5 yr
Width
4 in

Certifications and Compliance

Country of Origin
Mexico
Features
  • The nLight Bridge increases the number of lighting control zones in an nLight system with each Bridge having 8 RJ-45 ports that are daisy-chained to other nLight devices to create zones forming an integral component of the communication backbone in an nLight network
  • The nLight bridge allows you to control more lighting fixtures and control devices on the nLight lighting controls network
  • nLight lighting controls
  • Energy Management Equipment, UL916 (E167435), RoHS, Plenum UL2043
  • Low Voltage Output Ratings 15VDC, 40mA per RJ-45 Port (90mA total with connected PS-150 or PS-150-347 power supply, Mounting Directly to 4 x 4 Square Box, Surface Mount,
